Improving on the popular MS Super 5E, the MX5 is engineered for home and day spa steam rooms up to 822 adjusted cubic feet (ACF). Required control package sold separately.
The Mr. Steam MX5E is designed to provide years of safe, reliable, and efficient operation. The steam unit features a full-port drain valve, ASME safety valve, electronic water-level control system, and LED color light indicators for easy-to-read visual diagnostics.
Constructed of surgical-quality stainless steel throughout, the MX5E generator offers long-lasting strength and durability. The unit is equipped with durable electronic components and runs off an advanced microprocessor platform, making it the perfect option for large residential and commercial bathing applications.
MS MAX Series generators feature the modular Plug and Play option so that you may easily add steam shower accessories such as ChromaTherapy, SteamLinx, and AromaTherapy.
The Mr. Steam MX5E 24kW steam generator is available in 208V and 240V single-phase (1PH) configurations. MS-eSeries generators come in various power ratings to best suit your needs.
The compact size of the generator, about the size of a briefcase, allows the unit to be installed conveniently out of sight up to 60 feet away from the steam room. The MX5E is perfect for any home steam shower kit.
The optional Express Steam feature features a built-in thermostat that maintains water temperature so that you may start steaming quickly.
The MX5E generator requires a control or control package for operation. MX Series generators are compatible with all Mr. Steam controls and the Steamlinx mobile application.
The MS MX5E steam bath generator is fully serviceable and carries a limited lifetime warranty. Mr. Steam generators are US and Canadian UL listed and CE and NOM certified for your safety.
All Mr. Steam generators are designed, engineered, and constructed in the USA.
- 24kW Steam bath generator, 27-5/8" x 20-3/4" x 7-7/8"
- Installation and operation manual
- Limited warranty
- For steam baths sized from 679 to 822 adjusted cubic feet
- Available in 240V and 208V operation
- Stainless Steel tank
- Industrial-grade, serviceable heating element
- MiniDIN control connections
- Available Auto Drain automatic draining system
- Durable electronic components
- Electronic water-level control system
- Low-voltage safety control circuits
- Solid-state circuitry
- Diagnostic LED Displays
- Full port drain valve
- ASME safety valve
- UL/CUL/NOM/CE Listed
|Minimum Adjusted Cubic Feet||679|
|Maximum Adjusted Cubic Feet||822|
|Shipping Weight||67 lbs|
|Kilowatt Rating||24 KW|
|Electrical Specifications||Electrical Chart|
|Water Supply Connection||3/8" NPT|
|Generator Steam Line Connection||3/4" NPT|
|Steam Head Connection||1/2" NPT|
|Drain Connection||1" NPT|
|Safety Relief Valve Connection||3/4" NPT|
|Safety Relief Valve PSIG||15 PSIG|
|Control "Rough In" Cut Out||1"|
|Generator Control Connection||8-Pin Mini-DIN Connector|
|Generator Control Cable||30', 8 Conductor, 24 AWG, Shielded Cable|
